Mini Tractor 1004D
Overall Dimension (L×W×H)：4600 *2200 *2950mm
Min. Operating Weight：3900 kg
Wheelbase：2240 mm
Wheel Track (Front/Rear)：1600–1950 / 1620–2100 mm
- Efficient global shipping
- High quality product guarantee
- Products can be customized according to your needs
- Comprehensive customer service process
Product Description
The 1004 Heavy-Duty Tractor represents the peak of professional agricultural power, featuring a massive 3900 kg operating weight for maximum traction and stability. It is powered by a high-torque YTO 6-cylinder engine delivering a steady 100 HP, specifically designed for large-scale farming and heavy industrial hauling.
This flagship model utilizes an advanced TDF 16F+8R gearbox with shift sleeve technology, offering precise speed control for complex operations. With a reinforced chassis, 2240 mm extended wheelbase, and oversized 16.9-34 rear tires, the 1004 heavy-duty version provides unmatched ground clearance and pulling force for the most demanding soil conditions.
Product Parameters
| Category | Item | Specification |
| Dimensions & Weight | Overall Dimension (L×W×H) | 4600*2200*2950 mm |
| Min. Operating Weight | 3900 kg | |
| Wheelbase | 2240 mm | |
| Wheel Track (Front/Rear) | 1600–1950 / 1620–2100 mm | |
| Engine | Model / Brand | YTO YT0110HP Stage II |
| Type | Vertical, water-cooling, four-stroke, common rail | |
| Cylinder Count | 6 | |
| Rated Power | 100 HP / 73.5 kW | |
| Rated Speed | 2200 r/min | |
| Drive Train | Clutch | Single disc, dry, independent control, dual stage |
| Gearbox | TDF 16 Forward + 8 Reverse | |
| Gear Shift Type | Shift sleeve | |
| Steering & Brake | Steering Type | Full hydraulic steering |
| Brake Type | Mechanical control, wet, disc | |
| Walking Device | Tire Size (Front/Rear) | 7.5-20 / 16.9-34 |
| Working Device | Suspension Type | Rear, three-point suspension, Category II |
| Adjustment Mode | Height adjustment, floating control | |
| Hydraulic Output | 2 groups | |
| Standard PTO Speed | 8 or 6 keys; 760/850 or 540/1000 rpm | |
| Safety | Protection | ROPS (Roll-over protection structure) |
