Mini Tractor 2204G
PTO power:137.5KN
Rated Traction:47.5KN
Wheelbase:2820MM
Rated Power:162KW
Rated Speed:2200R/MIN
Max. Torque:1080N.M
- Efficient global shipping
- High quality product guarantee
- Products can be customized according to your needs
- Comprehensive customer service process
Product Description
The 220HP tractor features a thickened shell design, significantly enhancing its load-bearing capacity to easily handle heavy-duty operations. All gears adopt a helical tooth meshing structure, effectively preventing tooth breakage, ensuring smoother engagement, and remarkably improving transmission efficiency.
The entire vehicle is equipped with high-seal oil pipes, boasting excellent pressure resistance to ensure the hydraulic system operates smoothly without obstacles. The braking system uses hydraulic disc brakes, which deliver strong braking force, outstanding anti-thermal fade performance, and simple yet reliable operation.
It is powered by a domestic well-known engine, with Dongfanghong as standard and Yuchai as an option, ensuring reliable quality control. With a power reserve exceeding 20% and sufficient torque reserve, it provides strong and stable power output. The LED digital instrument panel clearly displays vehicle status, offering a car-level driving experience.
The hydraulic three-point linkage is of Class 3, equipped with a quick-hitch device, and comes standard with three sets of hydraulic outputs, compatible with various hydraulic agricultural machinery. Its multiple series of flexible transmission ratios can accurately meet the operational needs of different customers, making it a capable assistant for efficient agricultural production.
Product Parameters
| Category | Item | Unit | Specification Value |
| Basic Parameters | Dimension (L×W×H) | mm | 5800×2800×3350 |
| Min. Operating Weight | kg | 7700 | |
| Wheelbase | mm | 3000 | |
| Wheeltrack (Front/Rear) | mm | 1720, 1820, 1940, 2040, 2140 / 1700~2400 | |
| Engine | Model | / | YUCHAI 220HP 6-Cylinder National III Emission Standard |
| Type | / | Vertical, Water-cooling, Four Stroke, Common Rail | |
| Quantity of Cylinders | cylinder | 6 | |
| Rated Power | HP/KW | 220HP / 161.8KW | |
| Rated Speed | r/min | 2200 | |
| Drive Train | Clutch Type | / | Single Disc, Dry, Independent Control, Dual Stage |
| Gearbox Type | / | TG32F+32R | |
| Gearshift Type | / | Synchronizer | |
| Steering System | Steering Type | / | Full Hydraulic Steering |
| Brake System | Brake Type | / | Hydraulic Brake, Wet, Disc |
| Walking Device | Tire Size (Front/Rear) | / | 16.9-28 / 20.8-38 |
| Suspension Device Type | / | Rear, Three-point Suspension, Category III | |
| Suspension Device Category | / | Category III | |
| Tillage Depth Adjustment | / | Height Adjustment, Float Control | |
| Hydraulic Output Domain | group | 4 | |
| Standard PTO Speed | r/min | 8-spline or 6-spline, 760/850 or 540/1000 | |
| Others | Rollover Protection Structure/Cab | / | Cab |
