Mini Tractor 2604G
Engine Brand:191.5KW
Rated Speed:2200r/min
Rated Traction:59KN
Wheelbase:2870MM
Front track:2015MM
Rear track:2300MM
- Efficient global shipping
- High quality product guarantee
- Products can be customized according to your needs
- Comprehensive customer service process
Product Description
The 260HP tractor is equipped with a 440L large main and auxiliary dual fuel tank, which can meet the needs of long-time operations and greatly improve work efficiency. The braking system uses hydraulic disc brakes, featuring strong braking force, excellent anti-thermal fade performance, and simple and reliable operation. It supports function expansion and can be optionally equipped with a limited-slip differential, making it more capable of handling complex terrains.
It adopts a universal joint drive shaft, which delivers large torque and high reliability. The internal structure includes four-stage deceleration, with the final drive being double-cone and planetary deceleration, and the central drive can be optionally equipped with a differential lock, ensuring efficient and stable power transmission. The mid-mounted cylinder is paired with an independent oil circuit full hydraulic steering system, with consistent left and right turning radii, enabling flexible and precise steering. With a maximum load capacity of 3300KG, the machine body is sturdy and durable, with strong load-bearing capacity.
The driving experience is upgraded: the aviation-grade widened air-cushioned seat enhances comfort and safety; the hydraulic power-assisted clutch pedal reduces the burden on the feet and alleviates driving fatigue; the side-mounted independent handbrake provides stable parking, further ensuring operational safety. It is an ideal choice for large-scale farmland operations.
Product Parameters
| Category | Item | Unit | Specification Value |
| Basic Parameters | Dimension (L×W×H) | mm | 5800×2800×3350 |
| Min. Operating Weight | kg | 8340 | |
| Wheelbase | mm | 3000 | |
| Wheeltrack (Front/Rear) | mm | 1720, 1820, 1940, 2040, 2140 / 1700~2400 | |
| Engine | Model | / | YUCHAI 260HP 6-Cylinder National III Emission Standard |
| Type | / | Vertical, Water-cooling, Four Stroke, Common Rail | |
| Quantity of Cylinders | cylinder | 6 | |
| Rated Power | HP/KW | 260HP / 191.1KW | |
| Rated Speed | r/min | 2200 | |
| Drive Train | Clutch Type | / | Single Disc, Dry, Independent Control, Dual Stage |
| Gearbox Type | / | TG32F+32R | |
| Gearshift Type | / | Synchronizer | |
| Steering System | Steering Type | / | Full Hydraulic Steering |
| Brake System | Brake Type | / | Hydraulic Brake, Wet, Disc |
| Walking Device | Tire Size (Front/Rear) | / | 16.9-28 / 20.8-38 |
| Suspension Device Type | / | Rear, Three-point Suspension, Category III | |
| Suspension Device Category | / | Category III | |
| Tillage Depth Adjustment | / | Height Adjustment, Float Control | |
| Hydraulic Output Domain | group | 4 | |
| Standard PTO Speed | r/min | 8-spline or 6-spline, 760/850 or 540/1000 | |
| Others | Rollover Protection Structure/Cab | / | Cab |
